Functional disconnection
Unipolar
Safety disconnection
Bi-polar
Safety cut-out technology
Bimetallic disk
Safety reset
Manual
Max room temperature
105 °C
Rated current / voltage
20 A / 250 V
Functional temperature (factory setting)
From 10 °C to 90 °C, according to Customer specification
Safety cut-out temperature (factory setting)
From 50 °C to 120 °C, according to Customer specification
Functional temperature hysteresis
8 °C +/- 4 °C
Standard stem lenght
280 mm
Stem lenght on request
185 mm / 220mm / 350mm / 400 mm / 450 mm
Electrical connection to heating element
Quick faston connection 6,3 mm x 1,0 mm
External regulation knob
With / Without
