SCREW-TYPE HEATING ELEMENT

Heating element with threaded flange for screw assembly

Thermowatt/ Applications/ Water heaters/ Heating elements/ Screw-type heating element
Easy screw assembly
Anode support
Quick plug-in system with Thermowatt stem thermostat
ITek Brazing - Thermowatt patent

CHARACTERISTICS

  • Brass threaded flange from 1''1/4 to 2''1/4

  • Thermostat pocket to control temperature
  • Female faston connections to ensure easy plug-in with Thermowatt thermostat
  • Customizable material (e.g., copper, stainless steel, high grade nickel alloy, titanium)
  • Customizable power, shape and connections
  • ITek Brazing, maximum performance patented solution suitable for all the materials
CONTACT US
Head type Screw
Screw material Brass
Screw thread From 1"1/4 to 2", according to Customer specification
Element material Copper / Stainless steel (AISI) / High grade nickel alloy (INCOLOY) / Titanium
Element diameter 8,5 mm
Element shape and dimension According to Customer specification
Rated voltage Up to 240 V single-phase or up to 480 V three-phase, according to Customer specification
Rated power According to Customer specification
Surface load Up to 20 W/cm^2
Thermostat and sensor pocket material Copper / Stainless steel (AISI) / High grade nickel alloy (INCOLOY) / Titanium
Thermostat and sensor pocket diameter 8 mm / 8,5 mm
Thermostat and sensor pocket lenght According to Customer specification
Electrical connection Faston terminals / Screw terminals, according to Customer specification
Anode connection With (M6 thread) / Without

CERTIFICATIONS

UL
US and CANADA Product security
EUROPE Product security
EUROPE Product security
